PE waste plastic film recycling granulator

PE recycling granulator and single screw plastic recycling granulator are suitable for crushing recycled materials such as PE/PP/ABS/PS/PC or waste plastic sheets. Large volume or crushed materials are conveyed to a single screw extruder through screw feeding, compressed and plasticized in the extruder, cooled and pulled, and then enter the granulator to be cut into particles

Quantity:
Availability:





Inquire Add to Basket

Product Description

Waste plastic recycling granulator, single screw plastic recycling granulator is suitable for crushing recycled materials such as PE/PP/ABS/PS/PC or waste plastic sheets. Large volume or crushed materials are conveyed to a single screw extruder through screw feeding, compressed and plasticized in the extruder, and removed of ink moisture by a dual vacuum system. After filtration, they are cut into particles.

The PE plastic recycling granulator includes equipment such as feeding machine, single screw extruder, vacuum exhaust system, screen changing system, cutting system, drying system, etc.

Specification:

Specification	LJ110-125	LJ135-150	LJ160-180	LJ190-200	LJ210-230	LJ250-280
Output(t/d)	2.5-4	3.5-5	4-6	6-8	8-10	18-22
Power(kw)	30-40	50-70	80-110	160-180	200-240	370-410
Weight(kg)	2500-3000	4200-5000	5000-7000	6400-8500	7500-9700	11000-14000
Dimension(m)	8.41.42.2	121.72.6	162.12.7	212.43.4	3233.6	353.23.6

The process use of regenerated particles determines the filtration technology standards of the filtration system. For different melt filtration loads, conventional single plate/column dual station or non-stop dual plate/column four station screen changing filtration systems are applied to ASE recovery systems to achieve melt filtration performance.

The control system adopts Siemens PLC control and is equipped with industrial grade touch operation screen;

Intelligent activation: One click power on

Based on the pre-set logical sequence and material processing requirements, the linked ASE system achieves one click startup, thereby avoiding errors that may occur during manual startup.

Intelligent shutdown: One click shutdown

With the help of specially customized PLC units, the ASE system can achieve one click shutdown of the entire system module to avoid equipment damage caused by incorrect operations during manual shutdown.

Emergency stop device

ASE has an emergency stop function, which is used to quickly shut down the entire system in case of uncertain risks during machine operation, avoiding secondary accidents and injuries.

Protection system

Life safety protection device

The ASE system fully considers the safety issues of equipment during operation. Each operating station and rotating component position is equipped with electronic safety switches to ensure the safety of the equipment during operation and avoid potential hazards that may cause harm to customer operators.

FAQ:

:Q:Are you machinery factory or trading company?

A:We are machinery factory with 20 years experience in Shandong. And we can export machines by ourselves.

Q: Which kind of machine do you make?
A: We mainly produce plastic recycling machine,pelletizing machine and other auxiliary machine , It also includes a crushing and cleaning line, a complete process for waste plastic recycling, covering almost all functions of plastic machineryaccording to the different raw material, different output and different industrial voltage in working place,you can choose different machines.

Q: What kind of plastic is your machine used to recycle?
A:Our machines can be recycled PP/PE/LDPE/HDPE/ABS/PVC/PET etc all kinds of plastic material, according to different design of different plastic screw to achieve the result that customers want.

Q:Can you customized machine?
A:We can make the products following the customers' requirement,like the shape,size,color,logo and other spec details.
