LDPE single screw granulator for small waste plastic recycling

Plastic Recycling Granulator: This equipment is developed and produced by our company to address the complexity of the granulation process for paper mill waste plastics. This equipment is produced mechanically from material cleaning, impurity removal, separation of plastic paper and slurry, magnetic separation to molding, saving labor and effort, with a high degree of automation. It is a waste plastic treatment equipment for paper mills. For the plastic granulator used to pelletize the pulp plastic from paper mills, a special electric heating system, multi-mode mesh filtration, and large-scale pre-treatment and cleaning engineering are selected; Complete assembly line planning: single host dual auxiliary unit or dual host single auxiliary unit, three-step filtering, filtering well.

Quantity:
Availability:





Inquire Add to Basket

Product Description

Plastic Granulator: This set of equipment is developed and produced by our company for the complexity of the granulation process of paper mill waste plastics. This equipment is produced mechanically from material cleaning, impurity removal, separation of plastic paper and slurry, magnetic separation to molding, saving labor and effort, with a high degree of automation. It is a waste plastic treatment equipment for paper mills. For the plastic granulator used to pelletize the pulp plastic from paper mills, a special electric heating system, multi-mode mesh filtration, and large-scale pre-treatment and cleaning engineering are selected; Complete assembly line planning: single host dual auxiliary unit or dual host single auxiliary unit, three-step filtering, filtering well.

Plastic paper mill material granulation and extrusion three-step machine: This set of equipment is developed and produced by our company for the complexity of paper mill waste plastics in the granulation process. This equipment is produced mechanically from material cleaning, impurity removal, separation of plastic paper and slurry, magnetic separation to molding, saving labor and effort, with a high degree of automation. It is a waste plastic treatment equipment for paper mills. For the plastic granulator used to pelletize the pulp plastic from paper mills, a special electric heating system, multi-mode mesh filtration, and large-scale pre-treatment and cleaning engineering are selected; Complete assembly line planning: single host dual auxiliary unit or dual host single auxiliary unit, three-step filtering, filtering well.

Specification:

Model	LJ-110	LJ-125	LJ-150	LJ-180
Screw diameter	110mm	125mm	150mm	180mm
Main motor power	18.5kw	22kw	30kw	37kw
Screw rotation speed	40-65rpm	40-65rpm	40-55rpm	40-55rpm
Max. capacity	100kg/h	120kg/h	170kg/h	220kg/h
Pelletizer power	1.1kw	1.1kw	1.1kw	1.5kw
Crusher power	18.5kw	18.5kw	22kw	22kw
Washing machine power	7.5kw	7.5kw	11kw	11kw
Crushing and washing capacity	300kg/h	300kg/h	500kg/h	500kg/h
Size	6.5CMB	7CMB	9CMB	10CMB
Weight	2500kg	3000kg	4000kg	5000kg

Customer concern problem

Q:Are you machinery factory or trading company?

A:We are machinery factory with 20 years experience in Shandong. And we can export machines by ourselves.

Q: Which kind of machine do you make?
A: We mainly produce plastic recycling machine,pelletizing machine and other auxiliary machine , It also includes a crushing and cleaning line, a complete process for waste plastic recycling, covering almost all functions of plastic machineryaccording to the different raw material, different output and different industrial voltage in working place,you can choose different machines.

Q: What kind of plastic is your machine used to recycle?
A:Our machines can be recycled PP/PE/LDPE/HDPE/ABS/PVC/PET etc all kinds of plastic material, according to different design of different plastic screw to achieve the result that customers want.

Q:Can you customized machine?
A:We can make the products following the customers' requirement,like the shape,size,color,logo and other spec details.
