The core differences between twin-screw and single-screw granulators lie in structural design, mixing performance, and applicable scenarios. Twin-screw granulators exhibit significant advantages in terms of material mixing uniformity, exhaust performance, and processing of complex formulations, while single-screw granulators excel in structural simplicity and ease of maintenance.

1. Differences in structure and working principle

Comparison: Single Screw Granulator vs. Twin Screw Granulator

Number of screws: only one screw; two parallel screws placed in an "∞"-shaped barrel

The conveying method relies on friction to propel the material, which has the limitation of forced conveying due to "drag flow". The material migrates between the screws, forming an "∞" shaped trajectory, resulting in more stable conveying

Self-cleaning capability: Without self-cleaning function, residual materials tend to scrape against each other during co-rotation of the screws. It features a sealed self-cleaning function to reduce degradation risks

The modular design features a fixed structure with limited adjustment space. The cylinder and screw can be reorganized as needed, supporting independent control of multiple temperature and vacuum levels

II. Performance Comparison

Mixing and plasticizing effect

Single screw: It has a relatively weak shear force, suitable for simple melting and extrusion of thermoplastic materials;

Twin-screw: The shear rate in the meshing zone is high, and the mixing effect is far superior to that of a single screw, especially suitable for high filling, high viscosity, or blending of multiple materials.

Exhaust performance

Single screw: low exhaust efficiency, difficult to effectively remove volatile components;

Twin-screw: Adopting a starved feeding method, it can be equipped with an exhaust zone in the unfilled section, offering stronger devolatilization capabilities. It is suitable for processing PVC and heat-sensitive materials.

Material feeding control

Single screw: Relying on the friction coefficient between the material and the screw, it has poor feeding stability;

Twin-screw: It can achieve metered starved feeding, precisely control the feed rate, and enhance process stability.

III. Scope of Application and Typical Applications

Type Main use Representative material

Single screw granulator for extrusion of pipes, sheets, and profiles, and granulation of some modified materials such as PP-R pipes, PVC profiles, and PE film recycled materials

Twin-screw granulator for complex processes such as filling modification, alloy blending, reactive extrusion, scientific research and teaching, producing glass fiber reinforced PA66, flame-retardant PP, cable insulation materials, and degradable masterbatch

The small twin-screw models, such as the KY-Lab series, are widely used in laboratory research and development, supporting aspect ratios up to 40:1 and precise temperature control down to 350°C.

IV. Operation and Maintenance

Single screw: simple structure, low operational threshold, low maintenance cost, suitable for small and medium-sized production;

Twin-screw extruder: With a complex structure, it requires professional personnel for debugging and maintenance. However, it supports functions such as screen changing without stopping the machine and forced feeding, making it suitable for continuous and intelligent production lines.
