Outer coil stainless steel reactor

The outer coil reaction pot is mainly composed of a pot body, a pot cover, a stirrer, a heating jacket, a shaft seal transmission device, and supports. Material options include stainless steel such as SUS304 and SUS316L

1. Heating methods include electric heating, oil heating, steam heating, water heating (or cooling), outer coil tube semi-circular tube heating, etc. The jacket forms are divided into jacket type and outer half tube type, and the jacket electric oil heating type is equipped with a guide device.

2. Cooling methods include jacket cooling water cooling or cooling water cooling through coils inside and outside the kettle.

3. The mixing forms generally include paddle type, anchor type, frame type, screw type, scraping wall type, combination type, etc. The high-speed category includes dispersed impeller, turbine, high shear, and thruster types, for customers to choose their process flow.

4. The transmission forms include ordinary motors, explosion-proof motors, electromagnetic speed regulating motors, variable frequency motors, etc. The reducers include cycloidal pinwheel, helical gear, and planetary infinitely variable speed.

5. The shaft seal forms include ordinary water-cooled packing seal, magnetic seal, mechanical seal, and magnetic fluid seal.

6. The discharge forms include ball valves, downward expansion valves, butterfly valves, etc., which can be optionally selected.

Application industry:

The construction principle and characteristics of the outer coil stainless steel reactor:

The reaction kettle consists of a pot body, pot cover, stirrer, jacket, support and transmission device, shaft sealing device, etc. The material and opening can be customized according to the user's process requirements. Heating methods include electric heating, oil heating, gas heating, water heating (or cooling), open flame heating, etc. The jacket forms are divided into jacket type and outer half tube type, and the jacket oil heating type is equipped with a flow guide device. The mixing forms generally include paddle type, anchor type, frame type, screw type, scraping wall type, etc. The high-speed category includes dispersed impeller, turbine, high shear, and thruster types, for customers to choose according to the process. The transmission forms include ordinary motors, explosion-proof motors, electromagnetic speed regulating motors, frequency converters, etc. The reducers include cycloidal pinwheel, worm gear, and planetary infinitely variable speed. The shaft seal includes ordinary water-cooled packing seal, combined PTFE packing seal, and mechanical seal. The discharge forms include ball valves and downward expansion valves. Stainless steel reaction kettle with outer coil tube - high quality and low price

The equipment mainly consists of three parts: tank body, jacket, and mixing system.

1. Material of stainless steel reaction kettle

The parts in contact with the materials are made of high-quality stainless steel such as 304 or 316L, which meets GMP standards.

2. Accessories for stainless steel reaction kettle

The mixing method often uses frame mixing to ensure that the materials are evenly mixed in a short period of time; At the same time, frame type, anchor type, slurry type, etc. can be selected according to needs

The sealing adopts sanitary mechanical seals, which can ensure the pressure inside the tank and prevent unnecessary pollution caused by material leakage inside the tank;

The interface adopts ISO standard quick release clamp type, which is convenient for hygiene;

◆ Aseptic respirator, CIP cleaning nozzle, sight glass, flange, sanitary quick opening manhole, etc

3. Surface treatment of stainless steel reaction kettle

The inner surface is polished with a mirror finish to ensure no hygiene blind spots, and the fully enclosed design ensures that the material is always in a sterile state. The outer surface can be treated with sandblasting, sanding, or cold rolling with natural color matte finish.
