The ribbon mixer is primarily used for mixing various materials to achieve a uniform ratio

The ribbon mixer is an important industrial equipment primarily used for mixing various materials to achieve a uniform ratio. The following are the types of materials it can mix:

Powder and powder.

Powder and liquid.

Paste-like, viscous material.

Materials with a relatively high specific gravity.

The characteristics of the ribbon mixer include high efficiency, high uniformity, low energy consumption, low pollution, and low crushing, as well as simple structure, convenient operation, and easy maintenance. In addition, the ribbon mixer is suitable for various industries such as food, chemical, metallurgy, building materials, and medicine. It is widely used in pesticides, veterinary drugs, food processing, chemicals, biological products, aquaculture, ceramics, refractory materials, plastics, compound fertilizers, and other fields. The working principle of the ribbon mixer mainly relies on its special spiral blade design. These blades are usually double-layered or triple-layered, and through rotation, they push the material from one side to the other, forming convection mixing, thus achieving high standard mixing uniformity in a short period of time.

Discharging method of horizontal ribbon mixer: Powder materials adopt a pneumatic large-opening structure, which has the advantages of fast unloading and no residue; high-fineness materials or semi-fluid materials adopt manual butterfly valves or pneumatic butterfly valves. Manual butterfly valves are economical and practical, while pneumatic butterfly valves have good sealing performance for semi-fluids but are more expensive than manual butterfly valves. In situations where heating or cooling is required, a jacket can be configured. Heating methods include electric heating and heat transfer oil heating: electric heating is convenient, but the temperature rise is slow and energy consumption is high; heat transfer oil heating requires the configuration of an oil pot, oil guiding power, and pipelines, which requires a larger investment, but the temperature rise is fast and energy consumption is lower. The cooling process can directly inject cooling water into the jacket, which has a large heat exchange area and fast cooling speed. The motor and the main mixing shaft are directly connected through a cycloid pin wheel reducer, which has a simple structure, high operational reliability, and convenient maintenance.

The horizontal ribbon mixer is applied to the mixing of solid-solid (i.e., powder and powder) and solid-slurry (i.e., powder and slurry) mixtures in pesticides, veterinary drugs, food, chemicals, biology, aquaculture, ceramics, refractory materials, plastics, compound fertilizers, etc., and is particularly suitable for mixing viscous materials.
